To provide homeowners the most accurate representation of color options, several photo scans and house shots were utilized in various lighting conditions. Variations in lighting illustrate the color gradients on asphalt shingle roofs.
Color blends vary from shingle to shingle. Before installation, consult with your contractor and request to view the actual shingles being installed on your roof to ensure confidence in your final color selection.
Where To Buy
Get It Installed
March 04, 2019
Core4™ Enhanced Polymer Technology
June 08, 2018
Algae Resistant Roof Shingles By Atlas Roofing Featuring Scotchgard™ Protector
September 23, 2021
Atlas Signature Select: A Comprehensive Roofing System
June 21, 2017
Protect Your Home From Wind Damage - Atlas HP42 Technology
August 17, 2017
Atlas Roof and Home Design Studio
January 29, 2018
How to File a Home Insurance Claim After a Natural Disaster
September 20, 2017
3 Quick Tips to Help You Weather A Severe Storm
> VIEW ALL VIDEOS
Core4™ Technology is the most innovative development in asphalt shingle manufacturing.
Ask your insurance agent about discounts on your homeowners insurance when you install UL 2218 Class 4 Impact Resistant StormMaster® shingles.
Protect the investment in your home against high wind with an Atlas Wind Limited Warranty up to 150 mph*.
Atlas shingles featuring Scotchgard™ Protector help prevent ugly black streaks caused by algae.
Your home is the biggest investment you will ever make. You want to protect that investment by using quality materials and the best installation practices.
We want to hear from you!
When you choose Atlas shingles with Core4™ Technology, you can be sure that you are sheltering your family beneath the longest-lasting, most durable shingles in the industry.
Built with High PerformanceTechnology, these beautiful shingleswithstand winds up to 150 mph.
Inspired by Nature. Designed For You.
The colors of nature will be an integral part of your home when you choose the StormMaster® Shake Natural Expressions color palette. Make a statement with the bold, impactful, long-lasting colors of StormMaster® Shake Natural
For maximum protection and warranty coverage, install an Atlas Signature Select® Roofing System with components designed and backed by an Atlas Warranty.
1Atlas WeatherMaster® Ice & WaterUnderlayment
2Atlas Premium Underlayment
3Atlas Pro-Cut® Starter Shingles
4Atlas Roof Shingles
5Atlas TruRidge® & HighPoint®Exhaust Ventilation
6Atlas Pro-Cut® & StormMasterHip & Ridge Shingles
Atlas designer shingles with Scotchgard Protector help prevent black streaks caused by algae, keeping your roof looking beautiful for years.
Length: 42" / 1066.8 mmWidth: 14" / 355.6 mmExposure: 6" / 152.4 mm56 Shingles Per Square on AverageAlgae Resistant: Scotchgard™ ProtectorWind Speed Limit**: 130 mph w/ 4 nails
D7158, Class H Wind Resistance, Passed at 150 mphD6381, Uplift ResistanceD3018, Type 1D3161, Class F, Tested at 110 mphD3462, As ManufacturedE108, Class A Fire Resistance
790, Class A Fire Resistance2390, Class H Wind Resistance 2218, Class 4 Impact Resistance
CAN/CSA-A123.5-M90Florida Building Code Approved – FL 16305Miami-Dade County Product Control Approved
ATLAS ROOFING CORPORATION (“ATLAS”) warrants to you, the original owner of its shingle products, that this product is free from any manufacturing defects that materially affect the performance of your shingle during the Premium Protection Period or that cause leaks for the balance of the applicable warranty period.
ATLAS warrants that its shingles featuring Scotchgard™ Protector (those with the “featuring Scotchgard™ Protector” designation) will remain free of obvious and unsightly discoloration due to algae growth. For complete details, please see the Atlas Limited Shingle Warranty.
Your ATLAS shingles qualify for a limited warranty when properly installed in accordance with the product’s application instructions (as provided on the product packaging).* In order to qualify for the Atlas Lifetime Algae Resistance Limited Warranty against black streaks caused by blue-green algae, installation must include Atlas Pro-Cut® Hip & Ridge shingles featuring Scotchgard™ Protector or Atlas Pro-Cut® High Profile Hip & Ridge shingles featuring Scotchgard™ Protector with Atlas shingles featuring Scotchgard™ Protector. ** Refer to the Atlas Roofing Limited Shingle Warranty for all coverage requirements.
IMPORTANT: THE STATEMENTS EXPRESSED ON THIS PAGE ARE THE RECOMMENDATIONS FOR THE APPLICATION OF THE ROOFING PRODUCTS AS OUTLINED AND ILLUSTRATED. ANY DEVIATION FROM THESE RECOMMENDED PROCEDURES SHALL BE AT THE SOLE RISK OF THE INSTALLERS. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN SERIOUS DAMAGE TO THE APPLICATION AND LIFE OF THIS ROOFING PRODUCT, RESULTING IN THE TERMINATION OF ANY WARRANTY, EXPRESSED OR IMPLIED.
The lifetime limited warranty option is only available for individual single‐family site built detached residence. A 50 year limited warranty would apply to all property owned by government agencies, corporations, limited liability companies, partnerships, trusts, religious organizations, schools, or school districts, condominiums, or cooperative housing arrangements, or installed on apartment buildings or any type of building or premises not used by individual homeowners for a single family site built detached residence.
These shingles are warranted against manufacturing defects and wind gusts up to 130 MPH WITH STANDARD 4 NAIL INSTALLATION ONLY FOR SHINGLES WITH THE “BUILT WITH HP42 TECHNOLOGY DESIGNATION”.
The StormMaster® Shake Limited Warranty can be obtained by visiting www.AtlasRoofing.com/Warranty, or by writing to: Atlas Roofing Corporation, Attn: Consumer Services Department, 802 Hwy 19 N., Suite 170, Meridian, Mississippi, 39307. The following instructions must be followed to qualify for protection under the StormMaster® Shake Limited Warranty.
Important: See special instructions below for Low Slope Applications. See special instructions below for Steep Slope/Mansard/ 6‐Nail application. To obtain stated area coverage and to achieve design performance and appearance, the directions on this package must be followed. Sealing of the adhesive strips on each shingle to the shingle beneath is created by heat from sunlight. Atlas Roofing Corporation also endorses the Asphalt Roofing Manufacturers Association’s (ARMA) recommendations for application details not specified within this text.
Adequate ventilation under the roof deck must be provided to prevent harmful condensation in winter and heat build‐up in summer. These conditions can cause: A. Accelerated shingle weathering B. Deck rot and attic fungus C. Shingle distortion/ cracking due to deck movement D. Cosmetic blisters on the shingle surface. Atlas will not be responsible for damage to shingles as a result of inadequate ventilation. Ventilation provisions must meet or exceed current FHA Minimum Property Standards and conform to all building codes and regulations. To best ensure adequate ventilation and circulation of air, a combination of vents at the ridge and eaves should be used. All roof structures, especially mansard and cathedral type ceilings, must have complete through ventilation from eave area to the ridge area. FHA Minimum Property Standards require 1 square foot of net free attic vent area for every 150 square feet of attic floor area; or one square foot per every 300 square feet, if vapor barrier is installed on the warm side of the ceiling, or at least one half the ventilation area is provided near the ridge.
These instructions are for the application of Atlas asphalt shingles to nominal 3/8” or 7/16” thick American Plywood Association (APA/TECO) rated, code approved plywood, OSB decks or minimum ¾" actual thickness, wood decking . The plywood or non-‐veneer (OSB) decks must comply with the roof deck specifications of APA/TECO. Solid wood decking must be well seasoned, not over 6" (nominal) width, and fastened securely to each rafter. The deck surface must be clean, bare, gap free and flat. StormMaster® Shake shingles must not be applied to any surface other than roof deck types described here. Atlas also honors its Shingle Limited Warranty when Atlas shingles are installed on the Atlas CrossVent® Nailable Insulation panels. Atlas will not be responsible for the performance of its shingles if applied directly to non-‐vented, insulated decks composed of perlite board, plastic foam, fiberboard, gypsum plank, lightweight concrete, cementitious wood fiber, or similar materials or to any decks with insulation installed directly to the underside of the decking, with the exception of CrossVent® Nailable Insulation. Spray foam insulation applied directly to the bottom of the decking will void the warranty. Atlas shingles may be installed over a roof system containing a radiant barrier material if: 1. the required full, flow through ventilation is maintained directly under the decking material in all cases, 2. the radiant barrier material is highly vapor permeable ( > 2 perms), and, 3. the radiant barrier is installed on the underside of or below the decking – not used as an underlayment above the decking. Spray-‐on types of below deck vapor permeable radiant barriers will be considered only on a job by job basis, and only if tests confirm > 2 perms or greater vapor permeability.
All flashing should be in place before shingles are installed. Cap flashings of sheet metal and base flashings of metal or mineral surfaced roll roofing should be used at vertical surfaces such as chimneys, skylights, vents, walls, etc. All flashings should be sealed with asphalt plastic cement. Consult the Residential Asphalt Roofing Manual published by the Asphalt Roofing Manufacturers Association (ARMA) for details concerning specific methods and types of flashing installation.
Eave and rake edge waterproof flashings must be installed per local building codes and where there is a possibility of icing along the eaves and rake edges causing a potential for ice damming and a backup of water. Atlas’s WeatherMaster® products, or equivalent must be applied directly over the decking according to application instructions provided with the product, and local building codes. The waterproof flashing material must extend up the roof at least 24" beyond the interior warm wall line,
and in areas of severe icing, at least up to the highest water level expected to occur from ice dams. If the overhang requires flashing wider than 36", the horizontal lap must be located on the overhang area and cemented or sealed. End laps must be 12" (minimum) and cemented/sealed. WeatherMaster® products, as supplied by Atlas, are recommended as the first layer of Ice Dam Protection. WeatherMaster® products conform to ASTM D-‐1970.
Valleys must be installed before StormMaster® Shake shingles are applied.
Open Valley: Apply a 36" ice & water product centered in the valley. Install 16" wide minimum copper flashing (or equivalent) also centered in valley. Secure the copper flashing every 24" along both edges either with copper cleats or large head copper nails with the shanks immediately adjacent to the copper edge. Overlaps in the copper must be a minimum of 12".
Strike chalk lines on each side of the copper valley 3" from the center line. As shingles are applied, trim them to chalk lines and, to direct water into valley, cut 2" diagonally off upper corner of shingles adjacent to chalk line. Set valley edge of each shingle in a 3" wide band of asphalt plastic cement meeting ASTM D-‐4586 and nail no closer than 6" from valley center line. See Diagram #1.
Closed Cut Valley: Apply a 36" wide ice & water product centered in the valley, nailing 2" from outer edges only. Apply all shingles on one side of valley and across center of valley, a minimum of 12". Nail a minimum of 6" away from the center line of the valley on the unshingled side and strike a chalk line 2" from the center line on the un-‐shingled side. Apply shingles on the unshingled side up to the chalk line and trim. Do not cut the underlying shingle.
Cut upper corners of the shingle, cement and nail. See Diagram #2.
Placement of nails is critical to overall performance. High nail placement can result in separation of components and will cause delamination of the shingles after application. All nails must be driven straight with the heads flush to the shingle surface, never cutting into the shingle. Nails must not be exposed (visible) on the finished roof. Delamination after installation does not justify a warranty claim.
FASTENERS: Nails must be 11 OR 12 gauge corrosion-resistant roofing nails with 3/8" minimum head. Nails must be long enough to penetrate the roof deck 3/4" or if the deck is less than 3/4" thick, the nails should be long enough to penetrate fully and extend at least 1/8" through the roof deck. Nails may be placed in the sealant line.
NEW ROOFING APPLICATION (first shingle layer): 4 nails are required per shingle. The nails are to be located 7" up from the bottom edge of the shingle, with one nail placed approximately 1" from each side of the shingle, and the remaining two equally spaced between the two outer nails as illustrated in the diagram. NAILS MUST BE MINIMUM OF 1-1/4" LONG. See Diagram #3.
RE-ROOFING APPLICATION (second shingle layer): Requires the same nail placement as New Roofing. NAIL PLACEMENT IS IMPORTANT FOR WIND RESISTANCE. INCORRECTLY PLACED NAILS WILL VOID WIND COVERAGE OF WARRANTY. (See Section #12)
Immediately upon application to slopes exceeding 60°(or 21:12), apply six (6) quarter size spots of asphalt plastic cement under each shingle. All six spots are to be approximately 1" up from the bottom edge of the shingle and spaced equally across the shingle with the two outer spots located 1" in from each outer edge. The cement should not be exposed when shingles are pressed into position. Excessive
use of roofing cement can cause shingles to blister.
CAUTION: STEEP SLOPE AND MANSARD APPLICATIONS BOTH REQUIRE 6 NAILS EVENLY SPACED ALONG THE LENGTH OF EACH SHINGLE.
Use Atlas Pro- Cut® Hip & Ridge or Atlas Pro- Cut® High Profile Hip & Ridge (NOTE: Atlas Pro- Cut® Hip & Ridge featuring Scotchgard™ or Atlas Pro- Cut® High Profile Hip & Ridge featuring Scotchgard™ must be used as hip and ridge for the roof to qualify for Scotchgard™ Limited Warranty Coverage.) To prevent cracking in cold climates when applying to hips and ridges, shingles must be sufficiently warm and flexible. Apply Atlas Pro-Cut® Hip & Ridge shingles with a 5 5/8" exposure, beginning at the bottom of the hip or from the end of the ridge in the direction opposite of prevailing winds. Use two nails per shingle, as specified under Section 8– Fastening, with one nail on each side, 6" back from the exposed end and 1" up from the edge so succeeding shingles conceal nail heads. Trim final shingle to fit and set in plastic cement. See Diagram #6. When installing ridge vents follow vent manufacturer’s instructions.Separate the Pro-Cut® Hip & Ridge shingle into three equal pieces along the perforated lines provided. Bend each piece lengthwise to provide equal exposure on both sides of the ridge. Allow 5 5/8" of exposure and nail 6" from exposed butt edge with 2 nails—1" from each side. The direction of the exposed end should be away from the prevailing wind. One bundle of shingles will provide approximately 31 lineal feet of ridge coverage when applied in accordance with these instructions.
Replace all missing shingles. Split and securely nail all buckles, raised tabs or curled shingles. Ensure attic ventilation complies with FHA Minimum Property Standards as stated previously. Install a layer of number 30 felt underlayment to maintain a Class A fire rating. Asphalt Felt is to be applied over the old shingles and then proceed with the new shingles as if applying a new roof.
DIAGRAM 6 IMPORTANT: Atlas recommends 2" nails for a roof over. See Section 8.
ATLAS ROOFING CORPORATION DOES NOT APPROVE RE‐ROOFING OVER EXISTING WOOD SHINGLES OR LAMINATED ASPHALT SHINGLES.
MINIMUM STANDARD SLOPE REQUIREMENT AND INSTRUCTIONS APPLY TO NOT LESS THAN 4 INCHES PER FOOT. LOW SLOPE REQUIREMENT AND INSTRUCTIONS APPLY TO NOT LESS THAN 2 INCHES PER FOOT.
WARNINGS & PRECAUTIONS
WARNING: Roofing application can be dangerous. All necessary precautions and safety guidelines should be observed in accordance with proper roofing trade practices. Every effort should be made to keep roof traffic to a minimum. Regular roof maintenance should be performed in the cooler parts of the day.
Important Precautions: Store on flat surface. Protect from weather during storage and on job site. Sealant protection tape is placed on the back of each shingle and does not have to be removed before applying.
DISCOLORATION: Some shading or variations in the colors may occur due to positioning or embedment of the granule. When asphalt shingles are packaged, they are under a certain amount of pressure due to weight. Minor staining may occur. While in storage, they may also pick up varying amounts of backing material used to keep the shingles from sticking together. These discolorations are temporary and are removed by natural weathering.
